Cocktail audio x12

Revolutionary HiFi Audio System with all in One CD Storage

Smart HD Music Server, Network Streamer, NAS & much more

Cocktail Audio Pro X100

Cocktail Audio BF11 - Wi Fi, Bluetooth & AUX

Cocktail Audio Mini X9

‘Cocktail Audio’В is where media streamers meet HiFi components in a seamless manner.

Our focal points are onВ great sound, brilliance, integration, balance, upgradability, build, coupled with ease of use.

The cocktail Audio devices are excellent component with a high resolution playback that produces excellent sound. Revive old cassettes & LP collection back to life using our simplest tool like the mini X-9.

152-178 Kingston Road

New Malden, Surrey KT3 3ST

Sales : +44 (0)208 942 7575

Tel: +44 (0)208 942 01 11

Secure online shopping - accepted payments:

Cocktail Audioв„ў is a Registered Trademark

Cocktail audio x12

Yes, we collect bugs or requests for new function from customers, we normally post updated firmware on our website (www.cocktailaudio.com).

Yes, it supports. It supports audio file data CD that was burned with CD R/RW or DVD R/RW also. To play audio file data CD, you have to go to Browser after inserting CD into drive.

Yes, you can connect ANALOG OUT of the cocktailAudio and your amplifier with cable.

Yes, you can sort and search music by Artist, Album, Genre or Title.

Yes, install FreeDB data bundled with the cocktailAudio into the hard disk of the cocktailAudio.

No, you don't need to install FreeDB data in case that you use cocktailAudio with network (internet) connected.

Yes, if you want to use wireless LAN, you have to buy USB wireless dongle that our distributor supplies. Plug the USB wireless dongle into the USB host port of the cocktailAudio and setup it through SETUP menu.

Yes, you can use 3.5inch, 2.5inch SATA hard disk or SSD. You can open the hard disk door of the cocktailAudio and exchange it with ease. After installing brand new one, you have to format it with Linux or NTFS file system before using it.

The cocktailAudio provides two options. You can select 'Ripping All' for ripping all tracks one time, or 'Ripping Tracks' for ripping selected track only.

Yes, plug the memory stick into the USB host port of the cocktailAudio. Go into Browser, then you can see the USB. Press MENU and select 'Import to DB'.

Yes, go to Music DB and select music. Press MENU and select 'Export Songs'.

Connect the cocktailAudio and your computer through network. Go to Browser, then you can see the hard disk of your computer. Select the folder or music of your computer and press MENU. Select 'Copy to DB'.

Yes, place the cursor on the music you want to edit. Press MENU and select 'TAG Edit'

No, you can load(rip) with five(5) kinds of audio format such as WAV, MP3, FLAC, OGG or ALAC.

Yes, first you have to connect the cocktailAudio into network (internet). Go to Time set of SETUP, then you can select your time zone. Otherwise, you may set time at SETUP manually if you don't use network (internet).

The folder (Music DB) is hidden. You cannot see it. To delete the loaded (ripped) music, go into the Music DB icon and place the cursor on the music or album name which you want to delete. Press MENU and select 'Delete'

First you need an external USB HDD which has larger capacity than the Music DB data. Go to 'Setup' then 'Music DB' and select 'Backup' and confirm with OK button.

Yes, you can play music in your iOS devices on the cocktailAudio with 'Shareplay'. And you can control remotely using mobile devices like iPhone, iPad and Android devices if you install free UPnP app.

Yes, you can convert existing audio files into other formats like MP3, Ogg, FLAC, WAV, M4A or WMA. Go to 'Browser' and select the music which you want to convert. Press 'MENU' and select 'Convert Audio Format'.

Cocktail audio x12

HD HiFi Music Server with database, CD Ripper, High Quality DAC,

Built-in 60W Amplifier and Network Streamer

• CD Ripping with CD metadata including album cover art

• Load your vinyl and cassette tape colletions to the X12 in CD quality

• Streaming playback and control using mobile devices (UPnP/DLNA media server & renderer)

• Supported music streaming services: Qobuz, Simfy and Reciva internet radio

• Play songs from iOS devices on the X12 wirelessly with 'Shareplay'

• Fanless passive cooling system

• Supports up to 192KHz sample rate via Digital OUT

• 4.3inch TFT LCD screen with full color user-friendly GUI

including: iPhone, iPad and Android smartphones and tablets by download

Play songs from iOS devices on the X12 wirelessly with 'Shareplay'

Record from iRadio and Analogue IN in CD quality.

Schedule when you want the X12 to record with reservation recording

Absolutely silent with a SSD (Solid State Drive)

The perfect digital source for audiophiles

The X12 supports up to 4TB 3.5" and 2.5" SATA HDDs (Hard Disk Drives) and also SSDs (Solid State Drives)

High quality DAC with dynamic range 112dB (Max 2Vrms)

Intuitive user interface

Packed with features and yet simple to use the X12's operating system was developed by our inhouse R&D Centre

Set the X12 to record from multiple iRadio stations

Record from iRadio and Analogue IN in CD quality.

Schedule when you want the X12 to record with reservation recording

Import/Export music to/from the X12 Music DB via USB or over a network

Create and manage playlists, Edit music tag information, Music DB backup and restore, Auto Shutdown, HDD Sleep, Photo slideshow, Scroll speed control, Section Repeat, Ability to format internal and external storage, Resume play, File management, etc.

Cocktail Audio X12 CD Ripper Music Streamer and Integrated Amplifier

Plays, Streams, Rips, and Serves

Cocktail Audio's X12 is an HD hi-fi music server with database, CD ripper, high quality DAC, 30-watt-per-channel integrated amplifier, and network streamer. You can also enjoy its preamp functionality, listen to CDs, record analog and digital sources, and peruse its easy-to-navigate database of your digital music files, complete with cover art.

High Resolution Audio 24-bit/192 kHz

The X12 supports several different file formats including, including HD FLAC (24-bit/192 kHz), HD WAV (24-bit/192 kHz), APE/CUE, WAV, FLAC, ALAC, AIFF, AIF, AAC, M4A, MP3, WMA, Ogg Vorbis, PCM, M3U, PLS, and more. You can convert existing audio files into other formats, (e.g. MP3, FLAC, WAV, M4A) for use on other devices, such as your MP3 player or car stereo. The high-quality ESS Sabre 24/192 DAC has a dynamic range of 112dB.

Network Connectivity

Connect the X12 to your network via an Ethernet connection to stream music to and from other devices and listen to cloud based music services.

You can also connect wirelessly to the X12 using an optional Wi-fi USB Dongle (sold separately) that plugs into one of the USB ports. With the wireless function, you can greatly increase the control options and flexibility of this great component! You can control the X12 remotely using mobile devices including an iPhone, iPad, or iPod or using Android smartphones and tablets by downloading free UPnP apps. Play songs from iOS devices on the Cocktail Audio X12 wireless with the 'Share-play' function (Cocktail Audio 's own version of Apple AirPlay).

The X12 is a UPnP (DLNA) media server and renderer. This cool feature allows you to can stream music to and from other compatible devices, such as wi-fi speakers. (You can add wired speakers, too, and enjoy the built-in power amplifier.) Supported cloud-based music streaming services include Qobuz, Simfy and Reciva internet radio.

Digital and Analog Connections

The digital and analog connections let you enjoy lots of different source material. The three USB ports let you plug in external drives and devices, including a USB thumb drive, external hard drive, MP3 player, and more. An RCA-type analog stereo input excels with legacy analog gear, such as an AM/FM tuner, cassette deck, and more. You can record material from these components or enjoy them through your favorite pair of speakers, using the X12's built-in power amplifier.

Two digital outputs allow the X12 to connect to a wide range of external devices. The digital outputs support sample rates up to 24-bit/192 kHz for true hi-res audio. Gapless music playback keeps the music coming seamlessly and is a must for concert recordings, classical music, and more.

A digital volume control affecting both the digital and analog outputs allows the X12 to be used as a preamplifier if you are planning on connecting it to your existing hi-fi or AV system's receiver or amp.

Record Anything in CD Quality

Doing state-of-the-art digital isn't all that the X12 can do. It excels with analog source material, too. Whether you record iRadio or anything else via the analog input, Cocktail Audio X12 records in CD sound quality. Load your vinyl and cassette tape collections to the X12 in CD quality and edit them after recording.

And speaking of recording, using the display screen and built-in software, you can schedule when you want the X12 to record using the Reservation Recording function.

CD Play and Ripping

There is lots of fabulous music on compact discs that hasn't made it to downloadable files yet. Not to worry. Cocktail Audio has a built-in CD player plus ripping software, so you can record your favorite tracks. It supports CD, CD-DA, CD-R, CD-RW, and DVDR/RW discs.

For those times when you want to just lean back and listen rather than rip, you'll enjoy the full functionality of its audiophile-quality CD player. The large front-panel display makes navigating your discs a pleasure.

Built-in Database

The X12 gives you access to huge amounts of stored music. Fortunately, it provides easy access to all of your files through its well-organized built-in music database. The database can display all songs by album, artist, genre, composer or title, making it simple to find what you want to hear. Search functions give you even easier access to your music files. You can create and manage playlists, edit music tag information, and more.

Built-in Power Amplifier

No need for powered speakers or a separate amplifier with the X12. With its built-in high quality power amplifier, you can connect your own pair of audiophile speakers directly to the rear panel gold-plated speaker terminals. And the built-in amp is anything but an afterthought. It is a powerful amp capable of filling the room with music, thanks to 30-watts-per-channel power delivery.

Up to 4TB Storage Support

You can increase the huge capability of the X12 by adding your own internal hard drive. It supports up to 4TB 3.5" / 2.5" SATA hard disks. SSD (Solid State Drive) drives are also supported.

Overview

HD hi-fi music server with database, CD ripper, high quality DAC, and network streamer
Built-in 30-watt amplifier
CD Ripping with CD meta data including album cover art
Load your vinyl and cassette tape collections to the Cocktail Audio X12 in CD quality
Streaming playback and control using mobile devices (UPnP/DLNA media server and renderer)
Supported music streaming services: Qobuz, Simfy and Reciva internet radio
Supported audio formats: HD FLAC (24-bit/192 kHz), HD WAV (24bit/192KHz), APE/CUE, WAV, FLAC, ALAC, AIFF, AIF, AAC, M4A, MP3, WMA, Ogg Vorbis, PCM, M3U, PLS, etc.
Optional internal storage: supports your own internal hard drive up to 4TB 3.5" / 2.5" SATA hard disk; SSD (Solid State Drive) drives are also supported
Play songs from iOS devices on the Cocktail Audio X12 wireless with 'Share-play'
Fan-less passive cooling system
Supports up to 192KHz sample rate via Digital OUT
4.3" TFT LCD screen with full color user-friendly GUI
Gapless music playback
Supported media: CD, CD-DA, CD-R, CD-RW, DVDR/RW
Interface: Remote control, PC, iOS & Android devices with customized Web Interface (WUI) or various free UPnP Tablet & Smartphone Apps
Optional wi-fi with USB dongle

Connections

Digital outputs: Toslink optical, coaxial digital
Analog input: Stereo line input (RCA)
Analog outputs: pre out, headphone out, speaker terminals
Digital inputs: 3 USB host (1 front, 2 rear)
Network: Ethernet (100Base - Tx/10Base-T) LAN
Wireless network (optional): 801.11b/g/n wi-fiUSB dongle (sold separately)

Host CPU: Embedded 500Mhz MIPS
Main Memory: (2 Gbit, DDR2 667Mhz)
Firmware Memory: (2Gbit)
Pre out dynamic range: 112dB (Max 2Vrms, Stereo) Pre out THD+N: 0.001%
Dimensions: 7" wide, 3.9" high, 5.9" deep
